TF003
TANN FORGED WHEELS
Type: Cross country
Size: 17”18”19”20”21”22”23”24”
Process: Forged single piece structure
Load: Single hub load of 750KG actual load is set according to the model
Material: 6061-T6 aluminum alloy
Standard: JWL, VIA, DOT-T
Optional size range 》
- 17”
- 18
- 19”
- 20”
- 21”
- 22
- 23”
- 24”
SIZE | PCD | ET | CB | ||
17 | 9 | 5 / 6 | 114.3~139.7 | +25~40 | 60~125.2 |
9.5 | +25~40 | ||||
10 | +25~40 | ||||
SIZE | PCD | ET | CB | ||
18 | 9 | 5 / 6 | 114.3~139.7 | +25~40 | 60~125.2 |
9.5 | +25~40 | ||||
10 | +25~40 | ||||
SIZE | PCD | ET | CB | ||
19 | 9.5 | 5 / 6 | 114.3~139.7 | +25~40 | 60~125.2 |
| 10 | +25~40 | ||||
SIZE | PCD | ET | CB | ||
20 | 8.5 | 5 / 6 | 114.3~139.7 | +25~40 | 60~125.2 |
9 | +25~40 | ||||
| 9.5 | +25~40 | ||||
| 10 | +25~40 | ||||
| 10.5 | +25~40 | ||||
| 11 | +25~40 | ||||
SIZE | PCD | ET | CB | ||
21 | 8.5 | 5 / 6 | 114.3~139.7 | +25~40 | 60~125.2 |
9 | +25~40 | ||||
| 9.5 | +25~40 | ||||
| 10 | +25~40 | ||||
| 10.5 | +25~40 | ||||
| 11 | +25~40 | ||||
| 11.5 | +25~40 | ||||
| 12 | +25~40 | ||||
SIZE | PCD | ET | CB | ||
22 | 9 | 5 / 6 | 114.3~139.7 | +25~40 | 60~125.2 |
| 9.5 | +25~40 | ||||
| 10 | +25~40 | ||||
| 10.5 | +25~40 | ||||
SIZE | PCD | ET | CB | ||
23 | 10 | 5 / 6 | 114.3~139.7 | -17~50 | 60~125.2 |
10.5 | -11~55 | ||||
| 11 | -5~60 | ||||
| 11.5 | +1~65 | ||||
| 12 | +7~70 | ||||
| 12.5 | +13~75 | ||||
SIZE | PCD | ET | CB | ||
21 | 9 | 5 / 6 | 114.3~139.7 | -22~55 | 60~125.2 |
9.5 | -16~60 | ||||
| 10 | -10~65 | ||||
| 10.5 | -3 ~70 | ||||
| 11 | +3~75 | ||||
| 11.5 | +9~80 | ||||
| 12 | +16~85 | ||||
SHOW DETAILS
High quality high strength
